Classic 51.2V Lithium Battery
Aolithium 51.2V 100Ah server rack battery(LiFePO4) consists of 16 3.2V 100Ah Class A cells connected in series. With a stable configuration,making the quality reliable and lasting extremely longer. Own a 5.12kWh output energy, and support max 5.12kW load power draws, perfect for home emergency energy storage, and boat house bank batteries.
We only make the high-quality server rack battery.
BATTERY PACK
- Grade A Battery Cells
- Reliable 100A Built in BMS
- 16*3.2V 100Ah Prismatic Cells
CYCLE LIFE
- 4000+ Cycles @90% DOD
WATERPROOF/CORROSION-PROOF
- 6.0 Single pole angled connector (IP67), salt spray rating 144H
LIFESPAN
- 15+ Years Lifespan
More Comprehensive Certifications
Aolithium server rack batteries are the most fully certified batteries on the market. In addition to the required UL listing, we also carry UN38.3/ Class 9/ UN3480/ MSDS certification. This is the best battery safety guarantee.
Rare LCD Screen
The LCD screen will display the voltage, current, temperature and SOC of the server rack battery as it charges and discharges. You can see the battery status more visually without having to buy or use other tools to monitor it. Few vendors choose to use screens.
Compatible With 20 Types of Inverters
Aolithium server rack batteries are compatible with Pylontech, GoodWe, Deye, Megarevo , Victron and 20 other inverters. For parallel communication operation of multiple server rack batteries, dial-up address configuration is required. Our server rack batteries meet address 16, address 32, address 48.
Fearless of Extreme Weather
Our server rack batteries can operate well in extreme weather. With the protection of BMS, LiFePO4 batteries can be discharged normally even in extremely cold weather.
- Charging Temperature 32°F to 131°F
- Discharging Temperature -4°F to 140°F
- Storage Temperature: 14°F to 86°F
BMS With Equalization
- Single Cell Over-Voltage Protection
- Single Cell Under-Voltage Protection
- Battery Over-Voltage Protection
- Battery Under-Voltage Protection
- Charging & Discharge Over-Current Protection
- Output Short Circuit Protection
Not For Start-Up Application
- Do not use the battery for golf cart application.
- Can't be used as a starting battery.
Get the Power Company Off Your House
Our server rack batteries serve as a reliable home backup power source, supporting up to 16 batteries in parallel with a large capacity of 5120Wh, allowing you to power your important devices while you're at home. If you install solar panels, you can use the batteries as your energy storage, capable of providing uninterrupted power in the event of a power outage, which will save you thousands of dollars.
Faster Charging Speed
This rechargeable LiFePO4 battery has three 3 charging methods, you can choose the charger, or you can use solar energy. Aolithium's engineers have introduced you to charging methods.
Server Rack Battery Requirements Accessory List
Cables(AK01, AK02) and racks need to be purchased separately. Please select the number of cables you need according to the number of batteries purchased.
AK01 means long cables kit.
AK02 means short cables kit.
AK03 means racks.
Download
Please Note
- This model can be connected in parallel with up to 16 units to reach 8,192 watts
- Please do not connect in series.
- The bottom earth wire should be grounded.
FAQs
1) Recommend to fully charge the batteries before parallel connection.
2) The voltage of the two batteries should be the same when connected in parallel (error range 0.1V).
3) The cable length between batteries should be the same.
1) The SOC of the two batteries should be the same (small errors allowed).
2) The cable length between batteries should be the same.
You can't connect lithium battery and lead-acid battery together, and different brands of lithium batteries cannot be connected, because the batch of cells is not the same.
Even if it is the same brand, If the purchase interval is more than 4 months, it is also not recommended to connect.
Because the energy decay between the cells is not consistent.
The charging operation temperature is 0℃~55℃ (32℉ ~131℉)
The discharge operation temperature is -20℃～60℃ (-4℉ ~ 140℉)
If the battery is above or below these temperature ranges, the BMS will turn on the cut-off protection.
The length of time it takes to charge a li-ion deep cycle battery depends on the type and size of your charging source.
For example, if your charger is 20 amps and you need to charge an empty battery, it will take 5 hours to reach 100%, if your charger is 50 amps and you need to charge an empty battery, it will take 2 hours to reach 100%.
